| 序号 NO | 备件号 OPTION NUMBER | 备件名称 OPTION NAME |
| 1 | A3960376 | CONNECTOR,MALE 直通接头体 |
| 2 | A3922484 | CLAPBOARD,CONNECTION 连接隔块 |
| 3 | C3415394 | SCREW,DRIVE 自攻螺钉 |
| 4 | 3927772 | BEARING,CRANKSHAFT THRUS 曲轴止推瓦 |
| 5 | A3918673 | GASKET,GEAR COVER 齿轮室盖密封垫 |
| 6 | A3904679 | ROD,PUSH 推杆 |
| 7 | C3931623 | TAPPET,VALVE 挺杆体 |
| 8 | 81V46-04100 | COMPRESSOR,REFRIGERANT 空调压缩机总成 |
| 9 | 1601Z56-090 | PLATE,CLUTCH PRESSURE 离合器盖及压盘总成 |
| 10 | A3900267 | SEAL,GROMMET 复合密封圈 |
| 11 | A3900267 | SEAL,GROMMET 复合密封圈 |
| 12 | A3913845 | SEAL,O RING O型密封圈 |
| 13 | 11N-09074 | ELBOW,MALE ADAPTER 空压机进气接头 |
| 14 | C3903857 | SCREW,HEX FLANGE HEAD 减振器固定螺栓 |
| 15 | C3901249 | SCREW,HEX FLANGE HEAD 六角法兰面螺栓 |
| 16 | C4930591 | SWITCH,ENGINE BRAKE 油门开关总成 |
| 17 | 1306R2-010-B2 | THERMOSTAT 调温器总成 |
| 18 | 37V66-01010 | ALTERNATOR 发电机总成 |
| 19 | C3900631 | SCREW,HEX FLANGE HEAD 六角法兰面螺栓 |
| 20 | A3911584 | BELT,V RIBBED 多楔带 |
| 21 | C3903463 | COVER,ACCESS HOLE 燃油泵齿轮驱动孔盖 |
| 22 | 10Q04-01011 | SPACER,MOUNTING 前悬置右支架垫板 |
| 23 | C3967250 | SENSOR,TEMPERATURE 水温传感器 |
| 24 | C3967251 | SENSOR,OIL PRESSURE 机油压力传感器总成 |
| 25 | C3967252 | SENSOR,SPEED 转速传感器总成 |
| 26 | A3960076 | SUPPORT,FAN 风扇支架总成 |
| 27 | C3903990 | SCREW,HEX FLANGE HEAD 六角法兰面螺栓 |
| 28 | C3975392 | ELBOW,MALE ADAPTER 直角接头体 |
| 29 | A3355027 | HEAD,FUEL FILTER 燃油滤清器座 |
| 30 | C3936691 | TUBE,FUEL SUPPLY 燃油输油管 |
| 31 | A3910248 | PLUG,O RING 塑性堵塞 |
| 32 | A3960918 | PUMP,FUEL INJECTION 燃油喷射泵 |
| 33 | A3907978 | STUD 双头螺柱 |
| 34 | RQ65410-J8 | ELBOW,MALE ADAPTER 扩口式锥螺纹直角通接头体 |
| 35 | 1106N1-010 | PUMP,FUEL TRANSFER 柱塞式输油泵总成 |
| 36 | A3905307 | SCREW,BANJO CONNECTOR 琶形接头螺栓 |
| 37 | C3900269 | Washer,Plain 平垫圈 |
| 38 | 34N-05040 | ELBOW,MALE ADAPTER 弯管接头总成 |
| 39 | 3406N-001 | PUMP,HYDRAULIC 转向动力泵 |
| 40 | A3920551 | COVER,INTAKE MANIFOLD 进气管盖 |
| 41 | A3069053 | CLAMP,V BAND 夹紧卡环 |
| 42 | C3938158 | GASKET, CONNECTION 进气连接管管垫 |
| 43 | A3960749 | SCREW,HEX FRANGE HEAD CA 六角法兰面螺栓 |
| 44 | C3908118 | BRACKET,LIFTING 吊耳 |
| 45 | C3974406 | TAG,IDENTIFICATI 标签 |
| 46 | 1012N-010 | CARTRIDGE,LUB 机油滤清器总成 |
| 47 | A3907712 | DIPSTICK 机油标尺总成 |
| 48 | 1011N-010-A2 | PUMP,LUBRICATING OIL 机油泵总成 |
| 49 | A3901859 | SCREW,HEX FRANGE HEAD CA 六角法兰面螺栓 |
| 50 | C3900630 | Screw,Hex flange headcap 六角法兰面螺栓 |
| 51 | C3900630 | Screw,Hex flange headcap 六角法兰面螺栓 |
| 52 | 3957912 | SEAL,VALVE STEM 气阀杆油封 |
| 53 | A3283576ZZ | INJECTOR 喷油器组合件 |
| 54 | A3901356 | GASKET,TURBOCHARGER 增压器密封垫 |
| 55 | 10A-01041 | SUPPORT,ENGINE 支臂-飞轮壳 |
| 56 | C3968470 | SCREW,TWELVE POINT 十二角头螺栓 |
| 57 | C3911314 | DATAPLATE 标示牌 |
| 58 | Z*60205 | BEARING,MAIN 变速箱第一前轴承 |
| 59 | 37V66-08010 | MOTOR,STARTING 起动机总成 |
| 60 | C3929881 | GASKET,EXHAUST MANIFOLD 排气管垫 |
| 61 | A3906660 | MANIFOLD,EXHAUST 排气歧管 |
| 62 | A3960078 | HOUSING,THERMOSTAT 节温器座 |
| 63 | 11N27A-08380 | BRACE,ACCESSORY DRIVE 熄火拉丝固定板总 |
| 64 | L00393 | TOOL,SERVICE 服务工具 |
| 65 | C3900631 | SCREW,HEX FLANGE HEAD 六角法兰面螺栓 |
| 66 | A3902363 | SEAL,RECTANGULAR RING 矩形密封圈 |
| 67 | 81N-01017 | COUPLING,PLAIN HOSE 卡套式锥螺纹直通 |
| 68 | C3906697 | SEAL,RECTANGULAR RING 矩形密封圈 |
| 69 | C3008468 | PLUG,PIPE 内六角锥形螺塞 |
| 70 | A3906698 | SEAL,RECTANGULAR RING 矩形密封圈 |
| 71 | 12N-03051 | CLAMP,SPRING HOSE 卡箍 |
| 72 | A3960377 | ELBOW,MALE ADAPTER 直角接头体 |
| 73 | C3938158 | GASKET, CONNECTION 进气连接管管垫 |
| 74 | C3415519 | DATAPLATE 参数牌 |
| 75 | 3937214 | NOZZLE,PISTON COOLING 活塞冷却喷嘴 |
| 76 | A3918674ZZ | COVER,GEAR 齿轮室盖总成 |
| 77 | C3920781 | Screw,hex flange head ca 气缸盖螺栓 |
| 78 | C3900631 | SCREW,HEX FLANGE HEAD 六角法兰面螺栓 |
| 79 | C4987991 | DISC,CLUTCH 离合器从动盘总成 |
| 80 | A3907617 | GASKET,PUSH ROD COVER 推杆室盖垫 |
| 81 | C3900630 | Screw,Hex flange headcap 六角法兰面螺栓 |
| 82 | A3960345 | GEAR,ACCESSORY DRIVE 空压机齿轮 |
| 83 | Q351B22 | NUT,REGULAR HEXAGON 六角薄螺母 |
| 84 | C3958258 | DAMPER,VIBRATION 扭振减振器 |
| 85 | C4932506 | WIRE,GROUND 搭铁线 |
| 86 | C4945441 | SCREW, HEXAGON HEAD CAP 六角头螺栓 |
| 87 | C3901249 | SCREW,HEX FLANGE HEAD 六角法兰面螺栓 |
| 88 | A3924012 | BRACKET,BELT TENSIONER 皮带涨紧轮支板 |
| 89 | C3903475 | SEAL,RECTANGLE 矩形密封圈 |
| 90 | C4928870 | SUPPORT,FRONT ENGINE 发动机前悬置左支架 |
| 91 | C3901447 | SCREW, HEX FLANGE HEAD 六角法兰面螺栓 |
| 92 | C3999893 | CONNECTOR,MALE 直通接头体 |
| 93 | A3904362 | HEAD,FUEL FILTER 燃油滤清器座总成 |
| 94 | A3910260 | SEAL,O RING O 形密封圈 |
| 95 | A3923083 | HOSE,FLEXIBLE 燃油泵机油进油管 |
| 96 | A3960423 | TUBE,FUEL SUPPLY 燃油输油管总成 |
| 97 | A3920217 | TUBE,INJECTOR FUEL SUPPL 第1、2、3缸高压油总成 |
| 98 | C3900269 | Washer,Plain 平垫圈 |
| 99 | 34N-06025 | ELBOW,MALE ADAPTER 弯管接头总成 |
| 100 | 34N-06018-B | DISC,COUPLING 联轴节 |
| 101 | C3008468 | PLUG,PIPE 内六角锥形螺塞 |
| 102 | A3918800 | PIPE,AIR TRANSFER 进气过渡管 |
| 103 | C4938405 | CONNECTION,AIR INTAKE 进气接管 |
| 104 | A3960749 | SCREW,HEX FRANGE HEAD CA 六角法兰面螺栓 |
| 105 | C3910495 | SCREW,HEX FLANGE HEAD CA 六角法兰面螺栓 |
| 106 | C3975443 | COVER,PROTECTIVE 标签袋 |
| 107 | C3900632 | SCREW,HEX FLANGE HEAD 六角法兰面螺栓 |
| 108 | A3922886 | TUBE,OIL GAUGE 机油标尺管总成 |
| 109 | Q150B0830 | SCREW,HEXAGON HEAD CAP 六角头螺栓 |
| 110 | A3906696 | SEAL,RECTANGULAR RING 矩形密封圈 |
| 111 | C3902425 | SEALING WASHER 密封垫圈 |
| 112 | C3920400 | SCREW,HEX HEAD CAP 六角法兰面螺栓 |
| 113 | A3900276 | SPRING,VALVE 气阀弹簧 |
| 114 | A3283562 | INJECTOR 喷油器带密封垫总成 |
| 115 | C3818823 | STUD 双头螺栓 |
| 116 | Q150B1240 | SCREW,HEXAGON HEAD CAP 六角头螺栓 |
| 117 | C3930249 | SCREW,HEX FRANGE HEAD CA 六角法兰面螺栓 |
| 118 | C3281246 | Bracket,Lifting 前吊耳 |
| 119 | C3900627 | SCREW,HEX FLANGE HEAD 六角法兰面螺栓 |
| 120 | L00402 | BAG,SERVICE TOOL 服务工具包 |
| 121 | C3937706 | Gasket,Oil drain 回油管垫片 |
| 122 | A3902666 | GASKET,VALVE COVER 气阀室罩密封垫 |
| 123 | 81N-01021 | TEE,PLAIN ADAPTER 发动机出水管接头 |
| 124 | C3976084 | STUD 双头螺柱 |
| 125 | A3960342 | PUMP,WATER 水泵总成 |
| 126 | C3900589 | NUT,HEXAGON FLANGE 六角法兰面螺母 |
| 127 | A3960377 | ELBOW,MALE ADAPTER 直角接头体 |
| 128 | A3901090 | BEARING,MAIN 曲轴主轴瓦上瓦 |
| 129 | A3900709 | SEAL,OIL 曲轴前油封总成 |
| 130 | C3934920 | Support,Rocker lever 摇臂总成 |
| 131 | C3903112 | SCREW,HEX FLANGE HEAD CA 六角法兰面螺栓 |
| 132 | L00088 | STUD 双头螺柱 |
| 133 | C3900630 | Screw,Hex flange headcap 六角法兰面螺栓 |
| 134 | A3960376 | CONNECTOR,MALE 直通接头体 |
| 135 | Q40122 | WASHER,PLAIN 平垫圈 |
| 136 | C4932908 | FLANGE,CRANKSHAFT 曲轴法兰 |
| 137 | Q340B05 | NUT,HEXAGON I型六角螺母 |
| 138 | C3901249 | SCREW,HEX FLANGE HEAD 六角法兰面螺栓 |
| 139 | A3924026 | TENSIONER ,BELT 皮带涨紧轮 |
| 140 | C4928871 | SUPPORT,FRONT ENGINE 发动机前悬置右支架 |
| 141 | C3902114 | SCREW,HEX FLANGE HEAD CA 六角法兰面螺栓 |
| 142 | C3999916 | TUBE,AIR FUEL CONTROL 增压补偿管 |
| 143 | C3906694 | SEAL,RECTANGLE 矩形密封圈 |
| 144 | A3960410 | HOUSING,FLYWHEEL 飞轮壳 |
| 145 | A3931382 | GEAR,FUEL PUMP 燃油泵齿轮 |
| 146 | C3900631 | SCREW,HEX FLANGE HEAD 六角法兰面螺栓 |
| 147 | A3920218 | TUBE,INJECTOR FUEL SUPPL 第4、5、6缸高压油总成 |
| 148 | C3977274 | SCREW,HEXAGON HEAD CAP 六角头螺栓 |
| 149 | C3918109 | SCREW 螺栓 |
| 150 | C3883284 | SEAL,O RING O形密封圈 |
| 151 | C4983154 | TAG 标签 |
| 152 | C3906619 | PLUG, PIPE 六角头锥形螺塞 |
| 153 | C3900955 | PLUG,EXPANSION 碗形塞 |
| 154 | A3960717 | CONNECTION,SPACER 加机油口盖 |
| 155 | C3915703 | OIL PAN 油底壳 |
| 156 | C3959052 | Gasket,Oil pan 油底壳密封垫 |
| 157 | A3901117 | VALVE,INTAKE 进气阀 |
| 158 | C3909356 | Seal,Rectangular Ring 矩形密封圈 |
| 159 | C3818824 | NUT,HEXAGON FLANGE 六角法兰面螺母 |
| 160 | Q40312 | WASHER,SPRING 弹簧垫圈 |
| 161 | C3900632 | SCREW,HEX FLANGE HEAD 六角法兰面螺栓 |
| 162 | C3913638 | SCREW,HEX FLANGE HEAD CA 六角法兰面螺栓 |
| 163 | C3974118 | HOSE,FLEXIBLE 组合软管 |
| 164 | A3910824 | SEAL,O RING O 形密封圈 |
| 165 | C3977545 | Connection,Water inlet 安装托架 |
| 166 | C3900227 | SCREW,HEXGON HEAD CAP 六角头螺栓 |
| 167 | C3900632 | SCREW,HEX FLANGE HEAD 六角法兰面螺栓 |
| 168 | A3960572 | TUBE,CPR WATER OUTLET 空压机出水管 |
| 169 | A3901150 | BEARING,CRANKSHAFT THRUS 曲轴主轴瓦下瓦 |
| 170 | A3918675 | COVER,GEAR 齿轮室盖 |
| 171 | Q150B0875 | SCREW,HEXAGON HEAD CAP 六角头螺栓 |
| 172 | C4930901 | SUPPORT,REF COMPRESSOR 空调压缩机支架 |
| 173 | Q340B10-0H1 | NUT,HEXAGON I型六角螺母 |
| 174 | C3918614 | HOSE,PLAIN 曲轴箱通风管 |
| 175 | A3960376 | CONNECTOR,MALE 直通接头体 |
| 176 | Q40105 | WASHER,PLAIN 平垫圈 |
| 177 | C3903105 | SCREW,HEX FRANGE HEAD CA 六角法兰面螺栓 |
| 178 | C3900631 | SCREW,HEX FLANGE HEAD 六角法兰面螺栓 |
| 179 | Q150B1240 | SCREW,HEXAGON HEAD CAP 六角头螺栓 |
| 180 | C3914462 | PULLEY,FAN 风扇皮带轮 |
| 181 | C3906695 | SEAL,RECTANGLE 矩形密封圈 |
| 182 | C3008469 | PLUG,PIPE 内六角锥形螺塞 |
| 183 | A3960813 | SUPPORT,FUEL PUMP 连接板 |
| 184 | C3914284 | SPACER,MOUNTING 隔块 |
| 185 | A3960453 | MANIFOLD,FUEL 燃油回油歧管 |
| 186 | C3977274 | SCREW,HEXAGON HEAD CAP 六角头螺栓 |
| 187 | C3938152 | GASKET,INT MANIFOLD COVE 进气管盖密封垫 |
| 188 | C4983155 | TAG 标签 |
| 189 | C3942915 | Gasket,filter head 滤清器座密封垫 |
| 190 | C3920773 | WASHER,SEALING 密封垫圈 |
| 191 | A3901607 | VALVE,EXHAUST 排气阀 |
| 192 | C3280102ZZ | CAMSHAFT 凸轮轴组合件 |
| 193 | C4051052 | Turbocharger 增压器总成 |
| 194 | C3923331 | Gasket,Thm housing cover 节温器座密封圈 |
| 195 | C3967285 | BRACE,ACCESSORY DRIVE 油泵加速摇臂连接板 |
| 196 | C3975113ZZ | CONNECTOR,MALE 直通接头体组件 |
| 197 | A3960372 | COVER,VALVE 气阀室罩 |
| 198 | C4930589 | CONNECTION,WATER INLET 进水管 |
| 199 | C4928804 | GASKET,EXHOUT CONNECTION 密封垫 |
| 200 | A3960911 | TUBE,CPR WATER INLET 空压机进水管 |
| 201 | A3901258 | GEAR,CRANKSHAFT 曲轴齿轮 |
| 202 | C3900629 | SCREW,HEX FLANGE HEAD 六角法兰面螺栓 |
| 203 | C4930902 | SUPPORT,REF COMPRESSOR 空调压缩机支架 |
| 204 | Q40310 | WASHER,SPRING 弹簧垫圈 |
| 205 | C3990730ZZ | COVER,PUSH ROD 推杆室盖总成 |
| 206 | A3960678 | TUBE,LUB OIL DRAIN 空压机回油管 |
| 207 | Q40305 | WASHER,SPRING 弹簧垫圈 |
| 208 | C3976283 | BRACE,ALTERNATOR 发电机支架 |
| 209 | C3979347 | SCREW,HEXAGON HEAD CAP 六角头螺栓 |
| 210 | Q40312 | WASHER,SPRING 弹簧垫圈 |
| 211 | C3911446 | SCREW,BANJO CONNECTOR 琶形接头螺栓 |
| 212 | C3900629 | SCREW,HEX FLANGE HEAD 六角法兰面螺栓 |
| 213 | A3960814 | BRACE,FUEL PUMP 燃油泵固定板 |
| 214 | C3916361 | SCREW,BANJO CONNECTOR 琶形接头螺栓 |
| 215 | A3960617 | SUPPORT,TRANSFER TU 燃油回油歧管固定 |
| 216 |
